Stoll Loaders | Ag Attachments Limited

By Professionals for professionals

THE MEASURE OF ALL FRONT LOADERS

With the in-house developed drive-in system, which has been continuously further developed over decades, STOLL makes it possible for almost all tractor types to use a new quality swing arm - quickly and regardless of the year of manufacture of the series.

The 100% concentration on the development and production of front loaders and attachments from buckets to bale clamps makes STOLL the absolute market leader in Germany and specialists worldwide.

Enquire Now

ProfiLine Loaders Available Now!

Profiline FS FS Brochure

The Allrounder Brochure

Spare Parts Books

Fits All Major Brands

German quality @ NZ Pricing

CASE and NEW HOLLAND branded loaders also available

New Holland Liftarm Reference Sheet. pdf

Case Liftarm reference sheet. pdf

Comfort while working.Top performance in terms of lifting capacity and height. Top results in stability and loading speed. Comfortable to operate. The New Generation ProfiLine was specially developed to suit all professional needs.

For tractors between 50 and 300 HP (35-184kW)

FS = non self levelling

FZ = mechanical self levelling

Double acting lift rams on all models

MODEL FS 36-24

HP: 50-90

STD BUCKET: 1.5mtr

LIFT HEIGHT: 3.50mtr

LIFT CAPACITY: 1470kg

MODEL FZ 36-24

HP: 50-90

STD BUCKET: 1.5mtr

LIFT HEIGHT: 3.50mtr

LIFT CAPACITY: 1750kg

MODEL FZ 39-23

HP: 70-100

STD BUCKET: 1.7mtr

LIFT HEIGHT: 3.85mtr

LIFT CAPACITY: 1550kg

MODEL FS 39-27

HP: 70-110

STD BUCKET: 1.7mtr

LIFT HEIGHT: 3.85mtr

LIFT CAPACITY: 1580kg

MODEL FZ 39-27

HP: 70-110

STD BUCKET: 1.7mtr

LIFT HEIGHT: 3.85mtr

LIFT CAPACITY: 1800kg

MODEL FZ 41-29

HP: 90-140

STD BUCKET: 1.9mtr

LIFT HEIGHT: 4.10mtr

LIFT CAPACITY: 1930kg

MODEL FS 41-33

HP: 90-140

STD BUCKET: 1.9mtr

LIFT HEIGHT: 410mtr

LIFT CAPACITY: 1870kg

MODEL FS 43-34

HP: 120-180

STD BUCKET: 1.9mtr

LIFT HEIGHT: 4.32mtr

LIFT CAPACITY: 2080kg

MODEL FZ 43-34

HP: 120-180

STD BUCKET: 1.9mtr

LIFT HEIGHT: 4.32mtr

LIFT CAPACITY: 2430kg

MODEL FZ 46-33

HP: 150-230

STD BUCKET: 2.05mtr

LIFT HEIGHT: 4.55mtr

LIFT CAPACITY: 2590kg

MODEL FZ 48-42

HP: 180-270

STD BUCKET: 2.05mtr

LIFT HEIGHT: 4.80mtr

LIFT CAPACITY: 2790kg

1

When driving in, the front loader slides along the attachment until the locking pin meets the upper end of the connection support.

2 - With the Hydro-Fix all hydraulic lines can be connected to the tractor at the same time. The front loader is lifted slightly to hold the locking pin in position in the catch hook of the connection support.

2

With the Hydro-Fix all hydraulic lines can be connected to the tractor at the same time. The front loader is lifted slightly to hold the locking pin in position in the catch hook of the connection support.
