FARMER
FARMER
Manufacturer: Fieldmaster
The Farmer series is Fieldmaster entry level post driver ideal for larger life style blocks, small beef and dairy farm operations. Fitted with a 180kg weight and main lift ram makes smaller fencing jobs a breeze. A wide range of optional extras also enable the ability to customise a machine to your needs. The minimum required hydraulic oil flow for this machine is 18ltrs per minute.
DESCRIPTION
Features:
180kg (400lb) hammer
4.0m mast
3 bank control valve (2 spare banks)
Manual side angle
18 ltrs per min required at 1800PSI
New Zealand Made
SPECIFICATIONS
Feature | Farmer |
|---|---|
Standard Mast Length | 4m |
Weight (inc Hammer) | 420kg |
Standard Hammer Weight | 180kg |
Side Tilt Operation | Manual Screw Adjuster |
Top Link Operation | Tractor Top Link |
Linkage Mounting | Cat 1&2 |
Height Under Hammer (4m mast) | 3700mm |
Height Under Hammer (4.5m mast) | N/A |
Min Recommended PSI (Max) | 1800PSI (3000PSI) |
Min Hydraulic Flow (Max) | 18L/Min (60L/Min) |
Side Tilt Sngle (L to R) | 20/20 |
Top Link Angle (Fwd/Back) | 20/28 |
*Due to continuous manufacturing improvements specifications may vary
OPTIONS
230Kg Hammer weight
Hydraulic top link kit
Hydraulic side tilt kit
Top link extension bracket
Side mounting frames
Hydraulic side nudge ram
Closed circuit hydraulic valve system
OPERATORS MANUAL & SET UP VIDEO
Instructional Post Driver Set Up Video -
