UL SERIES ROTARY HOE
Manufacturer: Cosmo Bully
The European designed, COSMO UL Series Rotary Hoes are gear driven implements for compact and sub-compact tractors up to 40hp (max.). Engineered in Europe to till soil in nurseries, vineyards, orchards and hobby farms, they are ideal for owner operators. This forward-action rotary hoe features blades mounted in a speed configuration; blades staggered slightly from flange to flange. This design reduces horsepower requirements allowing the six blades to work the soil with a smoother result.
DESCRIPTION
Features:
PTO Drivehaft
Friction clutch
Height adjustable
3 models available
Optional 'speed blades'
CE Compliant
Suitable for subcompact tractors up to 40HP
1 year warranty
SPECIFICATIONS
Feature | TBUL36 | TBUL48 | TBUL60 |
|---|---|---|---|
Side Transmission | Gear drive | Gear drive | Gear drive |
Gearbox | 40hp, 540RPM, single speed | 40hp, 540RPM, single speed | 40hp, 540RPM, single speed |
PTO Shaft | Series 4 with 150mm (6") friction (slip) clutch | Series 4 with 150mm (6") friction (slip) clutch | Series 4 with 150mm (6") friction (slip) clutch |
Skids | Height Adjustable | Height Adjustable | Height Adjustable |
Finish | Powder Coated | Powder Coated | Powder Coated |
Rotor Diameter (mm) | 375 | 375 | 375 |
Rotor Speed (RPM) | 245 | 245 | 245 |
No. of rotor flanges | 4 | 6 | 7 |
No. of blades p/flange | 6 | 6 | 6 |
No. Blades | 24 | 36 | 42 |
Blades | Curved/speed | Curved/speed | Curved/speed |
Linkage | Cat 1 | Cat 1 | Cat 1 |
Guarding | Standard with CE Guards | Standard with CE Guards | Standard with CE Guards |
Overall Width (mm) | 1035 | 1340 | 1645 |
Working Width (mm) | 915 | 1220 | 1525 |
Working Depth (mm) | 165 | 165 | 165 |
Tractor Range (hp) | 15-28 | 20-35 | 30-40 |
Weight (kg) | 153 | 180 | 200 |
*Due to continuous manufacturing improvements specifications may vary
